Standard |
Tube 20mm, Bar 15mm, Plate 5x80mm |
Cutting whell size |
Outer diameter Ø150-160mm, Thickness 0.3-1.0mm, Inner diameter Ø25.4mm |
Max, vice circular width |
80mm |
Cooling grinding lubricant supply unit |
Max 45L/min |
Main spindle rotation frequency |
3000/3600RPM (50/60Hz) |
Motor |
Single phase 220V 50/60(Hz), 400W |
Dimensions |
400x650x1040mm |
Weight |
About 70Kg |
